Portable Glossmeter

Name: Portable Glossmeter
Brand: JAY INSTRUMENTS & SYSTEMS PRIVATE LIMITED
Price: 4000.00-17000.00 INR
Availability: InStock

Price 4000.00-17000.00 INR/ Piece

Get a Price/Quote

MOQ : 1 , , Piece

Portable Glossmeter Specification

Application
Gloss measurement of coatings, plastics, paper, metals, etc.

Temperature
0°C to 40°C

Automation Grade
Manual

Operating Voltage
3.7V (Battery)

Resolution
0.1 GU

Power Supply
Rechargeable Li-ion Battery / USB Charger

Display Type
Digital LCD

Equipment Type
Portable Glossmeter

Accuracy
±1.2 GU

Humidity
≤85% RH (no condensation)

Features
Compact, lightweight, ergonomic design, portable use

Specimen Size
Minimum 10mm x 10mm

Interface Type
USB

Number of Specimens
Single Sample Measurement

Test Range
0-200 Gloss Units (GU)

Measuring Range
0-200 GU

Response Time
<1 second

Mounting Type
Handheld

Usage
Gloss measurement

Machine Weight
Approx 500g

Test Width
Standard 1 cm aperture

Control Mode
Manual Operation

Data Storage
Up to 999 readings

Battery Life
Continuous use up to 50 hours

Calibration
Automatic / Manual Calibration Supported

Operating Language
English

Repeatability
±0.5 GU

Accessories Included
Calibration plate, carrying case, USB cable, user manual

Light Source
LED, Standard 60° geometry

Dimensions
Approx 160mm x 48mm x 75mm

Portable Glossmeter Trade Information

Minimum Order Quantity
1 , , Piece

Supply Ability
20 Pieces Per Week

Delivery Time
1 Week

About Portable Glossmeter

A Portable Glossmeter is mainly used to measure the mirror gloss of various flat products such as metal, paper, plastic, marble, paint, ceramics, etc. Not only suitable for carrying out, but also can be used on the operation table. It is compact and can be held with one hand. The test hole is under the host. When measuring, the glossmeter should be closely attached to the surface of the sample to be measured. The Portable Glossmeter is very useful and efficient.

Product details

Usage/Application	Industrial
Application	Industrial, Laboratory

Accurate Surface Gloss Measurement

Utilizing advanced optics and a standard 60 geometry, this glossmeter ensures high repeatability and accuracy for diverse applications. The digital display and rapid response time enable efficient assessments of gloss levels on coatings, plastics, metals, and paper surfaces.

Easy Calibration and Data Management

Automatic and manual calibration options allow users to maintain optimal measurement precision. With a generous data storage capacity for up to 999 readings, it facilitates reliable tracking and analysis over multiple tests and projects.

Portable and User-Friendly Design

Weighing approximately 500g and designed for handheld operation, this glossmeter is ideal for fieldwork and laboratory use. It features a robust rechargeable battery, ergonomic build, and comes equipped with a calibration plate, carrying case, USB cable, and user manual for immediate deployment.

FAQs of Portable Glossmeter:

Q: How do I calibrate the Portable Glossmeter before measurement?

A: Calibration can be performed either automatically or manually using the provided calibration plate. Follow the instructions in the user manual to select your preferred calibration mode and ensure the devices accuracy prior to taking measurements.

Q: What materials and surfaces can the glossmeter measure?

A: This glossmeter is suitable for measuring the surface gloss of coatings, plastics, paper, metals, and similar materials, making it versatile for quality control across various industries.

Q: When should I recharge the battery, and how do I do it?

A: Recharge the battery before use if the device indicates low power or after approximately 50 hours of continuous operation. You can recharge using the supplied USB cable and charger for convenient power management.

Q: Where can the Portable Glossmeter be used?

A: Its compact and robust design allows usage in laboratories, factories, workshops, or the field. The included carrying case facilitates safe transportation for on-site gloss measurement tasks.

Q: What is the process for taking a gloss measurement?

A: Place the sample with a minimum size of 10mm x 10mm under the 1 cm aperture, calibrate the device as instructed, and press the control button to record readings. Results are displayed instantly on the digital LCD screen.

Q: How is data stored and retrieved from the device?

A: The glossmeter can store up to 999 readings internally. Data can be transferred or accessed via the USB interface for further analysis and reporting, making it convenient for batch testing.

Q: What are the benefits of using this glossmeter for quality control?

A: This instrument offers accurate, repeatable gloss measurements with rapid response time, helping maintain product consistency, validate finishes, and comply with industry standards, ultimately enhancing quality assurance processes.
